Phihong POEA30U-1ATE-R Features

• Industrial External-Desktop, Single Port, PoE Injector
• Output: 56 volts, 0.536 amps, 30 watts, 1G data speed
• Output Connector: RJ45 (details in datasheet)
• IEEE802.3at Complaint
• DOE VI Efficiency
View More
Australian GEMS Registered
Compact Size
Limited Power Source (LPS)
IEC 60320-C14, 3-prong AC inlet
Full Over-Voltage and Over-Current Protection
Non-Vented Case
1 Year Warranty

POEA30U-1AT Series Description: The Phihong POEA30U-1AT Series is a 30 Watt single port Power over Ethernet injector designed to meet the IEEE 802.3at PoE Plus standard. It provides a 56 Volt DC output at up to 0.536 Amps and supports data speeds up to 10 Gigabit per second, ensuring compatibility with modern high performance network devices. The unit operates from a wide input range of 90 to 264 Volts AC and includes built in protection against over voltage, over current, and short circuit conditions. Its compact non vented case measures approximately 4.96 inches long, 1.79 inches wide, and 1.18 inches high for easy desktop or wall mounting. Equipped with an IEC320-C14 AC input and RJ45 data and power output ports, the POEA30U-1AT delivers efficient and reliable power for IP cameras, wireless access points, and VoIP phones.

For specific information on the Phihong POEA30U-1ATE-R please view the datasheet

Other models in the POEA30U-1AT series: 5G, 56 volt-POEA30U-1AT-5-R; 10G, 56 volt-POEA30U-1AT-X-R

---
