Product Specifications – HMCPS003A0W – Eaton Molded Case Circuit Breaker
-
Part Number:
HMCPS003A0W -
Manufacturer:
Eaton Cutler-Hammer -
Family:
Series C -
Pole:
3 -
Amp
3 -
Volt:
4 -
Phase:
3
-
Category:
Molded Case / 3-Pole -
Connection:
Feed-Thru -
Type:
HMCPS -
Functions:
I – Instantaneous -
Protection:
Magnetic Only -
AIC Ratings:
65kA@480V -
Frame Type:
F Frame
Dimensions
-
Dimensions (HxWxD):
B 4.8″ x 5.1″ x 7.6″
-
Weight:
4.55 lbs
Standards
Product Description – HMCPS003A0W – Eaton Molded Case Circuit Breaker
Cutler Hammer / Eaton / Westinghouse, Series C, type HMCPS, F Frame, 3P, 3PH, 3A, 600V, 65kA@480V, feed-thru, complete with non-interchangeable trip with I – Instantaneous Protection Only, non-aluminum line & load side lug terminals, style number 6601C87G50, MCP, motor circuit protector for application with motor starters equipped with electronic overload relays, magnetic range 9-30A, motor FLA 0.69-2.5A, magnetic only, molded case circuit breakers.
