MEAN WELL XDR-480-12PI Features

• AC-DC Industrial DIN Rail Single output power supply
• Output: 12 volts, 30 amps, 360 watts
• Connection Type: Push In Terminal (PI)
• 85~305Vac input range or 80~431Vdc input (derating 50% load at 80Vdc)
• Global certificates in multi-fields (ITE 62368-1, Industrial 61558-1/-2-16, 61010) & Marine DNV, SEMI47, CID2 HazLoc approved
View More
48mm ultra slim width
High efficiency up to 95.5% and no load power dissipation <1.2 W by R.C.
Built-in MODBus communication protocol
200% peak power capability
600% pulse current capability @15ms
Built-in constant current limiting circuit
Current sharing up to 1920W (3+1) for parallel use
Protections: Short circuit / Overload / Over voltage / Over temperature
Fanless design, cooling by free air convection
Over voltage category III (OVC III)
-40 ~ +85°C wide range operation temperature (>+60°C derating)
Operating altitude up to 5000 meters
Built-in remote ON/OFF control and DC OK relay contact
Ultra low inrush current < 6~15A
Conformal coating
Can be installed on DIN rail TS-35/ 75 or 15
5 year warranty

XDR-480(PI) Series Description: The MEAN WELL XDR-480 Series is a premium 480W AC/DC DIN rail power supply engineered for high end industrial applications requiring compact, efficient, and globally compatible power solutions. Its sleek 48mm ultra slim design optimizes space in densely packed control cabinets, enhancing system flexibility. With an ultra wide input range of 85~305Vac (or 80~431Vdc input), the XDR-480 seamlessly supports power grids worldwide, making it ideal for domestic or international deployments. Boasting a stellar 95.5% efficiency and a standby power consumption of less than 1.2W via remote control, this power supply delivers exceptional energy savings and supports eco-conscious operations. The fanless design ensures dependable performance across a wide temperature range of -40°C to +85°C (full load up to +60°C), while a conformal PCB coating provides resistance to dust and moisture. Equipped with a MODBus communication interface, constant current with up to 200% peak power, and the capacity to handle 600% instantaneous peak current, the XDR-480 excels in dynamic industrial settings. Additional features include parallel capability up to 1920W, DC OK, remote ON/OFF, and a built in ORing FET, complemented by versatile terminal block options (screw terminal, lever actuated or push in) and comprehensive protection mechanisms. Globally certified and backed by a 5 year warranty, the XDR-480 Series is a top tier, reliable choice for industrial automation, telecommunications, and smart control systems.

For specific information on the MEAN WELL XDR-480-12PI please view the datasheet

Other models in the XDR-480(PI) series: 24 volt-XDR-480-24PI; 36 volt-XDR-480-36PI; 48 volt-XDR-480-48PI
