• Double pole AC main circuit breakers with installed lockout slide
• Prevents connecting both AC sources simultaneously
• Maximum panel amperage – 50 Amperes
• Red reverse polarity indicating LED
• All hot, neutral and safety ground buses installed, fully pre-wired
• All circuit label positions are backlit on standard panels – No kit required
• “ON” indicating LEDs installed in all circuit positions
• Lifetime replacement warranty

SPECIFICATIONS:

• Part No.: 8132
• Source Selection: 2
• Amp Service: 16
• Nominal Voltage: 230V AC
• Height: 3.75in (95.25 mm)
• Width: 5.25in (133.35 mm)
• Weight: 1.35lb (0.61 kg)

INCLUDED:

Qty PN Product
2 7294 A-Series White Toggle Circuit Breaker – Double Pole 16A
1 8031 Basic AC Panel Label Set – 30 Labels [LABEL]
2 8134 LED – 250V AC Green
1 8166 LED – 250V AC Red
